TZone TZ TempU03
TZone TZ TempU03 – Multi Use Temperature Data Logger in Dubai
The TZone TZ Temp U03 is a multi-use USB temp and RH data logger that is compact and engineered for accuracy. It features temperature and relative humidity recording throughout the storage, transportation and distribution process. The USB data logger allows users to retrieve audit ready data without installing any additional software. Hence, it can automatically generate encrypted PDF and CSV reports.
The device features a built-in USB interface along with configurable alarm limits and logging intervals. This makes it appropriate to use in premises like refrigerated warehouses, pharmaceutical cold chains and food logistics. The temperature logger logs data for environmental monitoring. This helps address any issues that come up within regulatory compliance, as well as ensure product quality and decision making across operations.
Core Features
The data logger features data retrieval and automatic generation of encrypted PDF and CSV reports with a built in USB interface.
The device measures both temperature and relative humidity with high accuracy. It monitors sensitive products as a humidity logger during storage and transportation processes.
The TZone TZ TempU03 Multi Use Temperature Data Logger has configurable logging intervals as well as alarm thresholds with start and stop options. This makes the temperature monitoring much more flexible for various cold chain processes in Dubai.
Uninterrupted humidity monitoring is ensured with the large internal memory of 32,000 readings. This allows the equipment to adjust itself to long-term storage and transport.
The equipment is reusable and uses a replaceable CR2032 battery. This makes it possible for the temperature data logger to be used in several monitoring cycles.
Technical Specifications
Measured Parameters: Temperature and Relative Humidity
Temperature Measurement Range: -30°C to +65°C
Humidity Sensing Range: 0% to 85% Relative Humidity
Temperature & Humidity Accuracy: ±0.5°C (typical), ±3%RH
Memory Capacity: Up to 32,000 readings
Sampling Interval: Configurable from 10 seconds up to 18 hours
Interface: Built-in USB 2.0 with automatic PDF and CSV report generation
Battery: Replaceable CR2032 lithium battery
Dimensions: 89 × 36 × 16 mm
Net Weight: 25 g
Use Cases
- The temperature and humidity data logger monitors specimens, vaccines, biologics and temperature-sensitive medicines throughout pharmaceutical cold chains.
- It functions as an environmental data logger in hospitals and healthcare facilities of Dubai. This helps store blood products, medicines and laboratory samples in compliant conditions.
- The device supports an environmental monitoring system within food and beverage logistics. This records temperature and humidity in refrigerated transport and cold storage.
- The device is ideal as a multi-use temperature data logger for refrigerated warehouses and distribution centres. It helps to monitor inventory and reduces operational costs.
- The temperature and humidity monitoring system protects freezer samples as a reusable temperature data logger. The device provides fast and audit ready reports through the USB temperature data logger suitable for shipment verification of sensitive materials.
Frequently Asked Questions
Q1: What is the TZONE TZ TempU03 and what is it used for?
Ans:- The TZone TZ TempU03 is a multi use USB temperature and humidity data logger that is designed for repeated monitoring. It can record environmental conditions across cold chain logistics, pharmaceutical and medical storage, laboratories, warehouses and shipping containers.
Q2: Is the TZ TempU03 a single-use or reusable temperature data logger?
Ans:- The device is not a single-use logger but a multi-use data logger. The logger allows users to download the recorded data once a monitoring cycle is complete. After this, the logger can be configured for the next monitoring cycle.
Q3: What temperature range can the TZ TempU03 monitor?
Ans:- The temperature can be recorded from -30°C to +60°C. This range supports a variety of applications that include refrigerator monitoring, storage and transportation.
Q4: What is the temperature accuracy of the TZ TempU03?
Ans:- Across -20°C to +40°C, the accuracy is ±0.5°C. Outside this range, the specified accuracy is ±1.0°C, with a temperature resolution of 0.1°C.
Q5: How many temperature records can the device store?
Ans:- The device can store up to 32,000 readings. The actual number collected depends on the length of the monitoring period and the logging intervals.
Q6: Can the logging interval be customized before use?
Ans:- Yes. Users can configure the logging interval according to the shipment duration and other requirements. It can be customized from 10 seconds to 18 hours.
Q7: Does the TZ TempU03 support delayed start recording?
Ans:- It does. The TZ TempU03 supports a start delay of 0 to 254 minute . It can be programmed before the monitoring process begins to start at a predetermined time. This can be beneficial when the logger needs to be activated before the monitoring period starts.
Q8: How do I download temperature data from the TZ-TempU03?
Ans:- The logger has to be connected to a computer via its USB 2.0 interface after the monitoring cycle.The recorded measurements can then be accessed through the reports generated.
Q9: Does the device automatically generate a PDF temperature report?
Ans:- Yes. The logger can automatically generate a PDF report and a CSV file containing the recorded monitoring data when connected to a computer.
Q10: Is any software required to view the temperature report?
Ans:- There is no additional software required to view the temperature report. The logger can be directly connected to a computer to access the generated PDF and CSV report. It can automatically generate the report accordingly from the recorded data.
Q11: Does the TZ TempU03 provide alarm indications for temperature excursions?
Ans:- Yes, the default alarm limits are below 2°C or above 8°C. High and low alarm limits can be configured with an alarm delay. The settings are adjustable according to the monitoring application.
Q12: Is the device suitable for pharmaceutical and vaccine cold chain shipments?
Ans:- Yes, the device is designed for documenting temperature conditions during pharmaceutical and medical cold chain shipments. The logger’s range and configuration can be customized according to the vaccine or pharmaceutical product stored or transported.
Q13: Is it possible to use the TZ TempU03 for transporting food and laboratory samples?
Ans:- Certainly, one of the built in uses of the TZone TempU03 is food storage and lab applications. You can document environmental conditions easily with the temperature and humidity monitoring capabilities.
Q14: How long is the battery life of the TZ TempU03 for shipment monitoring purposes?
Ans:- The battery life of the device is normally one year. A CR2032 3.0V lithium battery powers the device. The sampling interval and operating conditions are some of the factors that affect the actual battery life of the logger.
Q15: Why choose the TZONE TZ TempU03 for cold-chain temperature monitoring?
Ans:- The device features humidity and temperature recording, storage capacity of 32,000 readings
